Firstly i find the whole drive to hydrogen to be essentially scientifically and engineeringly stupid. Understand that methane is chemically H3C and all the energy output comes primarily from the hydrogen. this happens to be also true for hydocarbons generally but packing a mass of low output carbon. thus the best known way to compress hydrogen as a fuel is with methane.
liquid methane needs pressure containers operating at around 16 athmospheres and not 700 athmospheres. for room temperature applications. This is still dangerous, but nothing like a hydrogen tank.
So why are we not using methane for fighter jets? If only, because the performance boost would be wonderful. Except a penetrating round would not be survivable. This does point to a low pressure tank system using some cooling and liquid boil off. that may not be impossible for carrier based operations when doubling the range might be the payoff. Likely need a jet fuel reserve tank though...
Hydrogen-powered business jet edges closer to certification
By David Szondy
March 26, 2026
Artist's concept of the BYA-I
Beyond Aero
If you've ever hankered after a hydrogen-powered business jet, your wait might not be much longer. French aerospace startup Beyond Aero's BYA-I One aircraft has completed its Preliminary Design Review, pushing it along the path to certification.
On paper, a hydrogen-powered business jet seems like a good idea. Hydrogen is about as green a fuel as you can get, producing only water as an emission and by using a fuel cell that runs electric propfans the resulting noise is much quieter than conventional gas turbines.
Mind you, there are a number of drawbacks, aside from not having anything like an actual hydrogen economy to supply the fuel – and certainly not one that doesn't depend on fossil fuels. Compared to conventional aviation fuel, hydrogen has a very low energy density, so you need a lot of it to do the same job. This is made worse by the fact that handling cryogenic hydrogen is extremely difficult, expensive, and requires a lot of specialized gear.
Diagram of BYA-I showing the hydrogen fuel tanks
Beyond Aero
Beyond Aero hopes to get around a lot of this by simplifying its design. Instead of using cryogenic hydrogen, the company is using gaseous hydrogen that's been pressurized to 700 atmospheres. This way, the BYA-I can rely on existing high-pressure technology that's already been developed, doing away with the complex ultra-cold liquefaction plants. This also makes thermal management much simpler and means that heavy Dewar tanks aren't needed.
Unfortunately, there's still the need for high-pressure carbon-fiber tanks where up to 44 lb (20 kg) of tank are required to hold each 2.2 lb (1 kg) of fuel. That not only adds dead-weight, it also hampers performance at high-altitude airports in hot climates.
However, the company shows considerable confidence in the advantages of the BYA-I. Designed for short-range flights of under 800 NM (920 miles, 1,482 km) at a cruising speed of 300 knots (345 mph, 556 km/h), it can carry up to eight passengers plus a crew of two for a maximum takeoff weight of 21,164 lb (9,600 lb).
The BYA-I refueling
Beyond Aero
Because of its redundant fuel cell configuration, the six 400-kW cells powering the turbofan motors are claimed to have a system resilience that rivals that of conventional engines. In addition, the zero-emissions powertrain makes the BYA-I immune to carbon taxes and "flight shaming" regulations.
Currently, Beyond Aero is seeking a CS-25/Part 25 certification from the EASA and the FAA, which is the highest standard of airworthiness that is normally reserved for large airliners. Apparently, the company is confident that its first-of-its-kind hydrogen powertrain will meet the stringent safety requirements so it can meet its service entry target of 2030.
"The Preliminary Design Review confirms that the aircraft configuration and its major systems – propulsion, hydrogen storage, aerodynamics and avionics – have reached the level of maturity required to support a certifiable architecture," said Luiz Oliveira, Chief Engineer at Beyond Aero. "With this milestone completed, the program moves on schedule into detailed design and verification of the aircraft’s integrated systems."
